| Brand Name : | RUSEN |
| Model Number : | PCS-A150-MG |
| Certification : | IEC/EN 62109-1/-2, EN 62477-1, IEC/EN 61000-6-2/-6-4, EN 50549-1/-10, NRS 097-2-1:2017 ASGC, GB/T 34120, GB/T 34133, CGC-R46103:2018A, PTPIREE REV1.2: 2024 TYPE B |
| Price : | Negotiable |
| Payment Terms : | T/T |
| Supply Ability : | 1000 |
| Delivery Time : | 3-30days |
• Adopting a compact architecture to achieve high-power integration
within a unit volume, suitable for space limited scenarios, and
balancing device miniaturization and high-power output
requirements.
• Dual backup of critical circuits and power supply, automatic
switching in case of failure, coupled with intelligent thermal
management system, ensures long-term stable operation without
interruption.
• Integrating efficient topology technology and energy optimization
algorithms to reduce energy loss and improve energy utilization in
scenarios such as energy storage grid connection and industrial
power supply.
| Model | PCS-A150-MG |
| DC(battery) | |
| Voltage range (V) | 420~850 |
| Max. current (A) | 405 |
| AC(on-grid) | |
| Max. output power (kW) | 165 |
| Rated output power (kW) | 150 |
| Rated voltage (V) | 400 |
| Voltage range (V) | 320~460 |
| Rated current (A) | 216 |
| Max. output current (A) | 238 |
| Rated frequency (Hz) | 50/60 |
| Frequency range (Hz) | 45~55 / 55~65 |
| THDi | <3% |
| Power factor | 1leading~1lagging(settable) |
| Grid type | 3W+N+PE |
| AC(off-grid) | |
| Rated voltage (V) | 400 |
| THDu | <1% Linear ＜5% nonlinear |
| Rated frequency (Hz) | 50/60 |
| Overload capacity | 110% long-term |
| General data | |
| Max. efficiency | 97.1% |
| Ingress protection | IP21 |
| Noise emission (dB) | <70 |
| Operating temperature (℃) | -30 ～ +55 |
| Cooling | Forced air |
| Relative humidity | 0 ~95% non-condensing |
| Max. operating altitude (m) | 5,000(>3,000 derating) |
| Dimension W*D*H (mm) | 800*800*1,900 |
| Weight(kg) | 1057 |
| Self-consumption | <0.5% |
| On/ off grid switching | Automatic |
| Display and communication | |
| Display | LCD touch-screen |
| BMS communication | RS485, CAN |
| EMS communication | RS485, TCP/IP |
| Certificates | IEC/EN 62109-1/-2, EN 62477-1, IEC/EN 61000-6-2/-6-4, EN
50549-1/-10, NRS 097-2-1:2017 ASGC, GB/T 34120, GB/T 34133, CGC-R46103:2018A, PTPIREE REV1.2: 2024 TYPE B |
|
|
